Adjustable pressure range: -1~-0.2, 0~20, 10~50, 10~100, 20~120, 50~150 bar

Electrical load: DC/AC 5V/12V/24/36V Max.1A; 50/60Hz AC 125V/250V Max.3A

Made using internationally advanced pressure diaphragm boxes and pressure pistons (SUS304/EPDM/Silicon/NBR/SUS304, optional),

it has excellent qualities such as easy pressure regulation, easy installation, precise pressure control, and stable performance.

It automatically measures the pressure inside the system to prevent it from being too high or too low and outputting switch signals.

Applicable fluid pressure media: water, hydraulic oil, steam, etc.

Widely used in hydraulic equipment, steam engines, water pumps, etc
